Hardware Performance

Chipset

Snapdragon SDX55, 5G SA/5G NSA/LTE

QCA6391

LTE

3GPP Release 15

Band Support

NR Sub- 6: N1/3/5/7/8/20/28/40/41/77/78

LTE: B1/3/5/7/8/20/28/40/41

Interface

3x GE RJ45, 1x FXS, 1x Micro(3FF) Sim Slot

LED

1x 5G,1x Mode,1x Signal,1x Wi-Fi,1x LAN

Button

1xReset

Antenna

6x Built-in 5G/LTE primary antennas

2x Built-in WLAN 2.4G/5G antennas

1 x Tx-9 connector for Rx(Optional)

1 x TS-9 connector for Tx(Optional)

Maximum TX power

5G/LTE

Conform to 3GPP Power Class 3/2, support HUPE.

RX sensitivity

5G/LTE

Conform to 3GPP Definition

Weight

865g

Power consumption

Max 17W

USB power supply

Input 12V/2A

Dimensions

95*100*205mm

Case material

PC,ABS

Temperature

Working temperature: 0°C to 40°C

Storage temperature:  -20°C to 60°C

Humidity

5%-95%（Non-condensing)

Gain

5G: about 4.5dbi

LTE: about 3.5dbi

WIFI: about 3dbi

Polarization

5G/LTE: Linear

WIFI: Linear

Cellular Wireless Network

Network

Search

Supports automatic or manual network search, the default is automatic

Connection Management

Supports automatic and manual connectionto the cellular network

Network Mode

Supports various network mode

Auto

5G SA

5G NSA

LTE only

Profile Management

Auto mode, set the profile information required for Internet access according to the SIM card automatically, avoid cumbersome operations for users

Profile name

APN name

User name

User password

Authentication type, auto/pap/chap

IP type, ipv4/6

Traffic statistics

Supports traffic statistics, including download, upload and total.

Wi-Fi

Wi-Fi settings

SSID/Key

Channel selection, auto or manual

Various security mode and algorithms

Disable

WEP (wired equivalent protocol)

WPA2 personal (Wi-Fi Protected Access 2 Personal), AES or TKIP

WPA2/WPA mixed mode (Wi-Fi Protected Access 2 Personal/Wi-Fi Protected Access Personal), AES or TKIP

WPA3 personal

Enable/disable SSID broadcast

max number of users up to 32

Enable/disable Wi-Fi

WPS

Wi-Fi Protected Setup (WPS) is a latest standard published by the Wi-Fi Alliance with the aim of simplifying the configuration process to establish a secure wireless home network.

The device Supports two WPS methods

PBC (Push Button Configuration), in which user simply has to push a actual button or virtual one on web UI

PIN (Personal Information Number), in which a PIN is entered into device through Web UI

MAC Address Authentication

Support the following MAC address authentication method

Black list

Router

The device works as a route, supports

Default gateway address: 192.168.8.1

Standard protocol such as ARP, ICMP, IPv4, IPv6, etc.

NAT, translate a public IP address to a private IP address and vice versa

DHCP server

DHCP server dynamically allocate IP address to client devices

Enable/disable DHCP server

Configures DHCP server address pool

Lease time, default as 86400 seconds

DNS relay

Supports DNS relay for client devices

Auto mode, use DNS servers from WAN

Manual mode, set primary DNS and secondary DNS manually

Basic

Status

Users can view the following basic device information on web UI

SIM status, Signal strength, roaming status

Operator name

Data transmission indication

Network access technology

Network Status

WAN IP

DNS

Wi-Fi Status

The number of devices connected to CPE and their details, including name, IP, MAC, etc.

Phone

Book

Supports contact group management

Add group

Delete group(s), batch operation is supported

View and modify existing group information

Supports search

Supports contact management

Add contact

Delete contact(s), batch operation is supported

Move contact(s) to group, batch operation is supported

Import contact from SIM card

Supports search

View contacts list, Supports pagination display

Modify existing contact information, including name, number, group, etc.

Select one or more contacts and send them a text message

SMS

Supports SMS (short message service) related functions

Inbox, outbox, and draft management

View list of messages, Supports pagination display

and detail of messages, including number, content, date, etc.

Edit, save, delete, and modify SMS

Sending short message to one or more contacts

Receives short message, new and unread message alerts

Replay and forward message

Supports various data coding scheme, GSM 7-bit and UCS

Supports normal message, up to 160 ASCII characters or 70 UCS2 characters

Supports long message (concatenated short messages), up to 612 ASCII characters or 268 UCS2 characters

Supports flash message

Security

The device supports the following security functions.

IP Filter

Port Filter

URL Filter

Port forward

DMZ

UPnP

DDNS

Firmware Update

FOTA

Provide complete FOTA solution

Detect new firmware information on FOTA server manually/automatically, including version, size, release date, and release note, etc.

Download new firmware from the server and update the device

The server initiates a firmware update for the specified device

Local

Update

Users can also upload firmware and update it through the Web UI

SIM Management

Supports PIN of SIM Card, including

Enable/disable PIN

Change PIN

Verify PIN

Reset Pin by PUK

VPN

L2TP, PPTP, IPSec

Customization

Functions

Web UI

SIM Lock

APN (Profile)

Trusted boot

Wi-Fi extender

USSD

Domain name

TR069
