Hardware Performance |
|
|
Chipset |
AN7563PT+MT7991B+MT7976C+EN8811 |
|
Interface |
1x 10/100/1000/2500M WAN port and supports Auto MDI / MDIX 3x 10/100/1000M LAN ports that support Auto MDI / MDIX |
|
Button |
Reset / Mesh (long press 5s reset, short press 1s WPS) |
|
LED |
1x Green/Red/Blue Status |
|
Antenna |
6x External Omnidirectional 5 dbi gain non-removable antenna |
|
Power |
DC 12V1.5A |
|
WIreless |
|
|
Basic function |
Wireless enabled / off SSID, broadcast enabled / off 2.4GHz Channel：1,2,3,4,5,6,7,8,9,10,11,12,13 2.4G frequency width: 20 MHz, 40 MHz 5G frequency width: 20 MHz, 40 MHz, 80 MHz, 160 MHz |
|
Frequency |
2412~2472M Hz 5170~5330M Hz ,5735MHz~5835MHz |
|
ThroughPut |
The 2T2R is up to 3600Mbps |
|
RF Power |
20 ± 3 dBm @ MCS13 |
|
Mode |
Router,Ap,WISP,Client+AP |
|
Wireless security |
Wireless MAC address filtering WPA-PSK, WPA2-PSK, WPA3 -SAE, WPA/WPA2-PSK, WPA2- PSK/ WPA3 - SAE WPS (PBC) |
|
Wireless Functions |
Wireless host status display Wireless site scan Seamless roaming between nodes Seamless roaming between frequency bands |
|
WiFi Setting |
Wi-Fi basic settings (dual frequency integration, switch, wireless mode, SSID, PWD, encryption algorithm, channel, bandwidth, power adjustment) Advanced Settings (Wireless Client Isolation, 802.11h, WMM Multimedia Acceleration) Multi- SSID (SSID, encryption method, PWD, encryption algorithm) |
|
Mesh |
Mesh Switch Role selection Networking mode Mesh-TOP |
|
Software |
|
|
Network status |
System status view: Device information (power-up time, system time, software version, hardware version)WAN dialing information, LAN status, WIFI information, IPv6 information, Mesh node information Mesh node information: Mesh networking node information, Mesh networking tutorial tips Client information: Support can directly pull the client into the blacklist Wifi information: Can directly jump to configure the wifi information Real-time speed display, WAN IP address display, software version information |
|
Network settings |
Support for WAN port connection type: PPPoE, dynamic IP, and static IP MAC address clone, IPTV settings |
|
LAN Settings |
DHCP server settings Manage IP settings |
|
Firewall |
Port mapping, DDNS, DMZ, WAN prevention PING, remote WEB management |
|
Parents control |
Online device display Online time Limited Internet time period URL filtering configuration |
|
Advanced setup |
Working mode, Bandwidth control, Sleep mode, LED control, Filter MAC address, Firewall, Static routing, DDNS, Virtual server, DMZ host, UPnP, TR 069 setting |
|
System management |
System status, time setting, password management, configuration management, and firmware upgrade |
|
System Tool |
Traffic Statistics System log Time zone setting Local WEB management control configuration File import and export Web software upgrade |
|
Others |
|
|
size |
278x179x33mm |
|
Environment |
Operating temperature: 0℃ to 40℃ Storage temperature: -40℃ to 70℃ Working humidity: 10% to 90% RH does not condense Storage humidity: 5% to 90% RH not condensing |
|
Packing Quantity |
20Pcs/box |
